| Operating Temperature Range | -40°C to +50°C |
|---|---|
| Humidity | 10–100% |
| Ingress Protection | IP67 |
| Operating Voltage | 4–28 V |
| Current Consumption | < 5 mA |
|---|---|
| Magnetic Field Strength (ON State) | 10–20 mT |
| Weight | 1,7 kg |
The HS125 is intended for operation with rod pump controllers and is used for dynagraph card generation and analysis. The system is resistant to external environmental influences, operates reliably across a wide temperature range, and is designed for easy installation and maintenance.
The HS125 sensor kit includes the following components:
