Load cell EMS150 and EMS151 are designed mainly for use in home automation or in automation for commercial spaces and light industry.
EMS151 generates un-amplified mili-volt signal from strain gauge. High accuracy is provided by precise manufacturing and temperature-compensated bridge of strain gauges, as well as by individual testing of each sensor after manufacturing.
Simple,robust and water-proof design allows universal use in various areas (for example monitoring the volume of water in the water tank, waste management monitoring etc.). Indoor and outdoor use.
Specifications:
• Rated capacity: 0-133,6 kN (30 klbs/ 13608 kg)
• Supply voltage: 9-15VDC
• Accuracy class: 0,5
• Compensated temperature range: – 40°C … + 60°C
• Operating temperature range: – 50°C … + 80°C
• Construction: Stainless steel
• Protection: IP65
EMS150 generates amplified volt signal from strain gauge. High accuracy is provided by precise manufacturing and temperature-compensated bridge of strain gauges, as well as by individual testing of each sensor after manufacturing.
Simple,robust and water-proof design allows universal use in various areas (for example monitoring the volume of water in the water tank, waste management monitoring etc.). Indoor and outdoor use.
Specifications:
• Rated capacity: 0-133,6 kN (30 klbs/ 13608 kg)
• Supply voltage: 9-15VDC
• Accuracy class (Load): 0,5
• Compensated temperature range: – 40°C … + 60°C
• Operating temperature range: – 50°C … + 80°C
• Construction: Stainless steel
• Protection: IP65
